Features Powered 15” subwoofer with 4” Voice Coil Maximum 136dB SPL and 33Hz-150Hz frequency range is ideal for today’s sound engineering demands High power 1600W Class-D amplifier module 96kHz DSP for true high-definition sound with super low latency Equipped with Dante I/O (2in/2out) and features SRC (sample rate conversion) allowing 48kHz device compatibility Access a variety of DSP functions and load presets, or make precise adjustments to PEQ, delay and routing etc. via the intuitive LCD display Equipped with D-XSUB processing and cardioid mode capability Lightweight yet very durable plywood cabinet with premium grade Polyurea coating Optional speaker cover (SPCVR-DXS15X) and wheel kit (SPW-1) Durable Black Specifications Speaker type: 2-way, Bi-amped Powered Speaker, Bass-reflex Frequency range: (-10dB) 44Hz - 20kHz Coverage area: H90? x V60? (Rotatable) Components LF: 10 Cone, 3 Voice Coil, Neodymium magnet Components MF: - Components HF: 2 Voice Coil, 1 Throat Compression Driver, Titanium diaphragm, Neodymium magnet Crossover: 1.8kHz (FIR-X) Sampling frequency: rate Internal 96kHz and FIR Filter A/D D/A Converters: 96kHz AD/DA Maximum output level (1m; on axis): 137dB SPL *1 SRC: Yes Dynamic 2000W (LF: 1000W, MF/HF: 1000W): *2 Burst (20ms): 1100W (LF: 1000W, MF/HF: 100W) Continuous: 950W (LF: 850W, MF/HF: 100W) Analog I/O: Analog IN: Combo x2, Line level (Maximum +24dBu), Input impedance 20kO, Analog OUT: XLR3-32 x2, CH1: THRU (fix), CH2: THRU or DSP OUT Digital I/O: Dante: etherCON CAT5e x2 (Daisy Chain), 2 IN / 2 OUT (Fs: 44.1k, 48k, 88.2k, 96k) and Remote Control, 1000BASE-T Others: USB2.0 Host 5V 500mA for USB memory DATA storage/load AC: IEC AC inlet x1 (V-Lock) Amplifier class: Class-D Cooling: Fan cooling, Variable speeds Power consumption: 45W (Idle), 150W (1/8) Handle: Aluminium die-cast, Top x1, Side x1 Rigging: M10 x8, M8 x2 Weight: 315 mm (12.4) Height: 537 mm (21.1) (with rubber feet) Depth: 345 mm (13.6) Net weight: 17.9kg (39.5lbs) Options: U-bracket: UB-DZR10H/V, Cover: SPCVR-DZR10 Others: Enclosure Material, Finish, Color: Plywood, Durable Polyurea Painting, Black/White Floor Monitor Angle: 50° Pole socket: F35 mm x2 (0° or -7°) WATCH: Yamaha Powered Loudspeaker DZR Series and Powered Subwoofer DXS XLF Series
