DITTO MIC LOOPER lets you go from idea to performance with ease in a flash. One knob, two buttons – it couldn’t be simpler! With its superior audio quality, unlimited overdubs and Undo/Redo, DITTO MIC LOOPER is the essential choice for looping vocals and instruments.
Features
- Simple two-button stompbox for vocal and acoustic instrument looping with unlimited overdub
- Dedicated stop switch gives precise control for record/play/overdub loop creation
- Versatile looper with superior audio quality, undo/redo, and unlimited overdubs
- Intelligent mic input gain for quick and painless setup
- Allows chaining to other TC Helicon vocal processors like HARMONY SINGER or MIC MECHANIC to expand creative possibilities
- High-quality, low-noise mic preamp for pristine vocals
- Compatible with remote Mic Control using the TC Helicon MP-75 or Sennheiser* e835 FX microphones
- Studio grade high-fidelity 24-bit uncompressed audio
- Rugged, road-worthy construction for years of dependable use
- Power supply included
- 3-Year Warranty Program*
- Designed and engineered in Canada
Specifications
Design
Dimension
- Height: 5.4 inches (140 mm)
- Width: 3.5 inches (90 mm)
- Depth: 2.3 inches (60 mm)
- Weight: 0.92 lb. (0.42 kg)
- Construction: Two part dies cast metal; Rubberized base
Connections
- Analog Inputs
- Input Connector: XLR Female, balanced
- Input Impedance: 2.7 kOhm balanced
- Maximum Input Level: -1 dBu
- Signal to Noise Ratio: 112 dB A-weighted
- Phantom Power: 32V (always on)
- Analog Outputs
- Output Connector: XLR Male, balanced
- Output Impedance: 250 Ohms balanced
- Maximum Output Level: -1 dBu
- Dynamic Range: >104 dB, 20 Hz to 20 kHz
- Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz
- Control
- USB for firmware and control
- Mic Control using TC Helicon MP-75 Microphone or Sennheiser e835 FX mic
Safety And Regulations
- Power
- Power Supply (Supplied): 12V .4A
- Power Consumption: 5.6W
- Safety
- EMC – Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
- Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA
- Environment:
- Operating Temperature: 32°F to 122°F (0°C to 50°C)
- Storage Temperature: -22°F to 167°F (-30°C to 70°C)
- Humidity: Max. 90 % non-condensing
- What's in the box?
- Region specific power supply
- USB cable
- User guide
Watch: Ditto Mic Looper - Live Session with Vocals, Double Bass, Trumpet, and Percussion
