Radial Key-Largo Keyboard Mixer

Designed for stage use, the Key-Largo allows you to connect up to three stereo keyboards, effects and volume pedals, and a laptop computer via USB, managing all these signals to send a balanced audio feed to a PA system for a seamless performance on stage. Three stereo analog inputs feature individual volume controls to balance levels, and each can be sent to a shared effects loop to add reverb or delay in an instant using a dedicated footswitch. A USB connection allows laptop computers to be integrated into the setup for control of soft-synths, and a built-in sustain footswitch and connections for a stereo volume pedal provide additional ways to control your performance. Features Three stereo analog inputs for keyboards Digital USB connection for laptop soft-synths On-board sustain and effects loop footswitches Separate balanced outputs for the PA and stage monitors Specifications Audio circuit type: Active circuit with audio-grade operational amplifiers Number of channels: 3x stereo analog inputs, 1x stereo USB input, 2x stereo analog outputs Frequency response: 20Hz - 20kHz ±0.5dB Gain: +12dBu Clip Level: +12dBu Total harmonic distortion: <0.005% @ 1kHz Input Impedance: Analog 20k Ohms Output Impedance: XLR: 300 Ohms 1/4: 450 Ohms Noise: -91dBu Noise: 24bit / 192kHz 180° polarity reverse, Ground lift, Level Control, Effects Loop Input Connectors: 3x Stereo Analog Inputs, 1 x Stereo USB Input Output Connectors: Stereo XLR Balanced Outputs, Stereo 1/4 Monitor Outputs Extras: Performance or Recording Mode Construction: 14-gauge steel Size (L x W x D): 8.4 x 5 x 1.9 (21.3cm x 12.7cm x 4.8cm) Weight: 3.25lb (1.47kg) Conditions: For use in dry locations only between 5°C and 40°C Warranty: Radial 3-year, transferable Watch: Radial Key-Largo Mixer and Performance Pedal
