Palmer PAN 02 Active DI Box

Standard active DI box. Can be operated with 9 V batteries or 48 V phantom power. High-impedance input; higher output level than a passive DI box. Active circuitry allows for high input impedance ( 1 meg. ohm) and higher input sensitivity (typical difference between in and out -4 dB). Key Features Active 1-channel DI box with premium balancing transformers 10Hz –40 kHz frequency response, high dynamic response -30 dB input attenuation, switchable Ground lift switch for each output Balanced mono summed output Can be powered with 9 to 24 V DC mains adapters or phantom power Technical Data Product type: DI Boxes Type: Active Inputs: 1 Input/Output Connectors: 1/4 Max. Input Level: +45dBu Input Impedance: (@ 60 Hz) 1 M Ohm(s) Input Pad: 0 / -30 dB Outputs: 1 Max. Output Level: +10dBu Output Impedance: 600 Ohm(s) Frequency Response: 10 - 20000 Transformer Balanced: Yes Operating Voltage: +48 V phantom power, 9 V block Power Consumption: 3.8 mA (9V), 4 mA (48V) Dimensions: 110mm x 73mm x 42mm 0.4kg
