We wanted to deliver a next-generation analog synthesizer for a new generation of musicians new to analog synthesis. That dream was realized in the development of the minilogue, which instantly made the analog synthesizer approachable.
In addition to emphasizing the same real analog sound and joy of controlling an electronic musical instrument offered by the original minilogue, the minilogue xd newly adds a digital multi-engine, effects, a powered-up sequencer, and micro tuning functionality, further expanding the possibilities for sound design and performance potential.
Minilogue xd is a fitting addition to the original groundbreaking Minilogue.
Features
- Analog synthesizer circuit that shatters expectations for its class
- Equipped with a digital multi-engine
- High-quality digital effects
- User customization brings out infinite potential
- Polyphonic step sequencer controlled by 16 buttons
- A thoughtfully designed interface
- A full complement of input and output jacks
Specifications
- 37-keys (Slim-key, velocity sensitive)
- Analogue sound generator + Multi digital sound generator (Noise, VPM, User)
- 4 voices
- 500 voices (more than 200 preload, 300 user programs).
Each program provides a program sort function that includes voice mode settings.
Favorite function built in.
- 4 (POLY, UNISON, CHORD, ARP / LATCH).
The VOICE MODE DEPTH setting allows different parameters to be varied for each mode.
- 16-step polyphonic sequencer
Motion sequence can be used on up to four parameters
- VCO1
- WAVE (SAW, TRIANGLE, SQUARE), OCTAVE, PITCH, SHAPE
- VCO2
- WAVE (SAW, TRIANGLE, SQUARE), OCTAVE, PITCH, SHAPE
- MODULATION
- SYNC, RING, CROSS MOD DEPTH
- MULTI ENGINE
- NOISE/VPM/USER, TYPE、SHAPE
- MIXER
- VCO1, VCO2, MULTI
- VCF
- CUTOFF, RESONANCE, DRIVE, KEYTRACK
- AMP EG
- ATTACK, DECAY, SUSTAIN, RELEASE
- EG
- ATTACK, DECAY, EG INT, TARGET (PITCH, PITCH2, CUTOFF)
- LFO
- WAVE (SAW, TRIANGLE, SQUARE), MODE（BPM, NORMAL, 1-SHOT), RATE, INT, TARGET (PITCH, SHAPE, CUTOFF)
- EFFECT
- TYPE (MODULATION, REVERB, DELAY), ON/OFF (SELECT, ON, OFF), TIME, DEPTH
- Noise Generator
- 4 types
- VPM oscillator
- 16 types
- User oscillator
- 16 slots
- CHORUS
- 8 types
- ENSEMBLE
- 3 types
- PHASER
- 8 types
- FLANGER
- 8 types
- USER
- 8 types
- DELAY
- 12 types
- USER
- 8 slots
- REVERB
- 10 types
- USER
- 8 slots
- Joy stick that can modify different parameters for each program, PORTAMENTO knob
- Main
- Real-time OLED oscilloscope provides visual feedback of parameter changes
- MULTI ENGINE section
- 7 segments x 6 digit LED display
- Headphone jack (Stereo phone jack)
- OUTPUT L/MONO, R jacks (monaural phone jack unbalanced)
- CV IN 1, CV IN 2 jacks (3.5 mm [1/8"] monoural mini jack, Input voltage: -5 V – +5 V (Modulation mode), -3V – +5 V (CV/Gate mode)
- SYNC IN jack (3.5 mm [1/8"] mini jack, maximum input level 20 V)
- SYNC OUT jack (3.5 mm [1/8"] mini jack, output level 5 V)
- MIDI IN jack
- MIDI OUT jack
- USB B jack
- DAMPER jack (half damper is not supported)
- AC adapter (DC9 V)
- 8 W
- 500 mm x 300 mm x 85 mm / 19.69" x 11.81" x 3.35"
- 2.8 kg / 6.17 lbs.
- AC adapter
- SC-MINILOGUE Soft shall case
- SEQUENZ MP-TB1 MULTI-PURPOSE TALL BACKPACK
- SQ-CABLE-6 Sync cable
- DS-1H Damper pedal
- PS-1 Pedal switch
- PS-3 Pedal switch
| * |
