Features
- 40 watts; Normal, Drive, and More Drive channels
- Celestion 12" A-Type speaker
- Modified preamp circuitry for increased overdriven note definition
- Spring reverb modified for improved smoothness
- Lightweight pine cabinet
- Includes 2-button footswitch and cover
MODIFIED PREAMP CIRCUITRY
The modified preamp circuitry offers greater tonal definition and clarity, even when pushing the amp into overdrive, so your tone remains articulate no matter how hard you push it.
MODIFIED SPRING REVERB
This amp’s modified spring reverb offers the same luscious ambient sound you know and love, but with improved smoothness to dial in your sound at any volume.
CELESTION SPEAKER
Hailing from the U.K., Celestion speakers are acclaimed worldwide for their distinctly rock ‘n’ roll flavor, with a more modern sound and utterly classic roar when pushed.
LIGHTLY AGED GRILLE CLOTH
The Hot Rod Deluxe IV features the classic Fender look of sparkling silver grille cloth, lightly aged to give it even more mojo.
LIGHTWEIGHT PINE CABINET
Lightweight, yet strong, pine was used to craft Fender amps in the 1950s and ’60s, making for more resonant and more “musical” speaker cabinets.
IVORY POINTER KNOBS
In a nod to our illustrious past, we added ivory pointer knobs, an original-era design element.
Specifications
ELECTRONICS
Voltage: 240V AUS
Wattage: 15 Watts
Controls: Presence, Reverb, Master Volume, Middle, Bass, Treble, Drive Select Switch, Drive Volume, Bright Switch
Channels: Three - Selectable (Normal, Drive and More Drive)
Inputs: Two - (1/4", Input 2 operates at -6dB)
Speaker Jack: Two 1/4" Parallel (Internal and External)
Effects: Reverb
Effects Loop: 1/4" - (Preamp Out, Power Amp In)
HARDWARE
Cabinet Material: Lightweight Pine
Amplifier Covering: Black Textured Vinyl
Grille Cloth: Lightly-Aged Silver
Amplifier Jewel: Red Jewel
Front Panel: Black
Handle: Molded Plastic Strap with Nickel-Plated Caps
SPEAKERS
Speakers: One - 12" Celestion® A-Type
Total Impedance: 8 ohms
TUBES
Preamp Tubes: 3 x 12AX7
Power Tubes: 2 x 6L6
Rectifier: Solid State
MEASUREMENTS
Amp Height: 18.75" (47.6 cm)
Amp Depth: 10.5" (26.7 cm)
Amp Width: 23.5" (59.7 cm)
Amp Weight: 41 lbs. (18.59 kg)
