When tuning in-ear monitors to accurately reproduce a recording of a live performance, our goal is for the sound hitting the eardrums to be identical to that at the original performance. To achieve this, the acoustic properties of the ear must be factored in.
The acoustic resonance and horn effects of the ear change a flat audio signal entering the open ear into sound with a (2700 Hz) high-frequency boost, which is the same response heard at the eardrum in a typical ear.
That is the reason for the “hump” in the frequency response graph, which assures the eardrums perceive a perfectly flat frequency response for all frequencies.
Specifications
- Frequency Response: 20 Hz – 15 kHz
- Transducers High-output: 6-mm neodymium moving coil drivers
- Noise Isolation: 35dB
- Using silicone ear tips: 42dB
- Using foam ear tips
- Impedance:32 Ohms @ 1kHz
- Sensitivity:
95 dB @ 1kHz
1mW Maximum Output (SPL) 120 dB
Cable: Fixed 4 ft cable with 3.5mm stereo plug
- User Replaceable ACCU-Filters:No
- Warranty:1 Year
- Custom-Fit Option:Yes
