Yamaha RUio16-D I/O rack-mounted audio interface with 16 inputs, 18-inch size, Dante and USB connectivity, black finish.
  • Yamaha RUio16-D I/O rack-mounted audio interface with 16 inputs, 18-inch size, Dante and USB connectivity, black finish.
  • Yamaha RUio16-D I/O rack-mounted USB audio interface with 18-inch, 16-out Dante connectivity and multiple input/output ports.
  • Yamaha RUio16-D I/O rack-mounted audio interface with 16 outputs, Dante and USB connectivity, and 18-inch size.
  • Yamaha RUio16-D I/O rack-mounted audio interface with 16 inputs, 18-inch design, Dante and USB connectivity, black finish.
Yamaha RUio16-D I/O Rack 18in 16out Dante USB Audio Interface

Brand: Yamaha

Yamaha RUio16-D I/O Rack 18in 16out Dante USB Audio Interface

SKU: VDP8250
$1,799.00
Available to Order
Price Match

  • Rent from

  • $149.92/mth for 12 months interest free

    Fees apply

  • $449.75 Pay in 4 interest-free

    Late fees apply

  • $449.75 Pay in 4 interest-free

    No fees or interest
Shipping Calculator

Enter a suburb for a more accurate quote. Final shipping cost is confirmed at checkout with the full delivery address.

Stock Availability

  • 0 Mega Music Myaree
  • 0 Mega Music Wangara
  • 0 Mega Music Warehouse
Want to click & collect, or try in-store?

Both our Myaree and Wangara stores are open 9–5:30pm Monday – Friday, with Myaree open 9–7pm Thursdays, both stores 9–5pm on Saturday and closed on Sundays.

Stock is live across all three locations and updates as stock is sold, however we still encourage you to call ahead to the store if stock indicated here is low at your preferred location.

Click and collect is a service offered at both store locations, which may require stock to be moved between stores or from the warehouse, as such we request that if you have ordered online, to please wait for a confirmation message before heading to the store.

If stock is only indicated at our warehouse location it can still be transferred to your desired store, even if you just want to try it, just get in touch with your desired store during store opening hours and make a request!

Please also be aware that unless you have paid a deposit to hold an item, it will remain free for sale on the web even if it has been set aside in-store. To avoid disappointment we always recommend a 10% deposit, this can be done in-store or online, just get in touch!
Description

Engineers, meet your newest partner.

The RUio16-D is a groundbreaking audio interface in a compact housing, yet rugged enough to withstand the rigors of touring, and acts as a bridge between Dante, analog, and USB signals. Pairing this interface with the included VST Rack Pro plug-in host software creates a plug-in platform that allows users the freedom to easily integrate VST plug-ins to the system. This device boasts a variety of input and output jacks that are useful in various situations, such as sending computer processed audio to a mixer via Dante, and a studio-grade preamp for acoustic measurement and other uses.
Features
  • Analog: 2 inputs, 2 outputs
  • Dante: 16 inputs, 16 outputs
  • USB: 18 inputs, 16 outputs
  • Bypass switch for preventing unexpected issues
  • Rack-mountable (using the M4-size screw holes on the underside of the product)

A compact yet rugged interface

The RUio16-D is compact enough to be held in one hand, making it easy to carry on board when traveling. Furthermore, the product is built inside a robust enclosure that can withstand the demands of touring. M4 size screw holes on the bottom of the case make the RUio16-D mountable on a rack shelf.

Enjoy a highly flexible plug-in environment

Engineers can use the RUio16-D in combination with the included VST Rack Pro software to create a stable plug-in environment. This setup allows the engineer to integrate their favorite pre-purchased VST3 plug-ins for live performance and studio use, as well as over 30 different standard plug-ins that come with VST Rack Pro.

Bypass function for minimizing potential trouble

A Bypass USB switch on the front of the RUio16-D bypasses audio transmission from the plug-in side. This feature is included should a problem occur with your computer and prevents issues that can cause sound to stop on the entire system.

The RUio16-D also features Dante redundancy, latches on the XLR connectors and a locking mechanism on the USB jacks that supply power, all painstakingly designed to minimize potential trouble.

Bundled with a wide variety of plug-ins
VST Rack Pro includes a suite of over 30 popular and incredible sounding plug-ins developed by Yamaha and Steinberg. These include the Buss Comp 369, acclaimed by RIVAGE PM users. REVerence, which offers sampled reverbs in stunning quality, SuperVision, which is useful for loudness management, and other plugins that can be used in various other applications. Add the RUio16-D and VST Rack Pro to your touring rig to get the sounds from the plugins you already know and love, wherever you may be. Specifications
  • I/O
    • Inputs: Analog Inputs (Mic / Line) x 2 (XLR)
    • Outputs: Analog Outputs x 2 (XLR)
    • Phones: x1 (TRS)
    • Dante I/O: 16 in / 16 out
    • Dante Connections: Primary / Secondary (etherCON)
    • USB I/O: 18 in / 16 out (USB 2.0)
    • USB Connections: USB 2.0 (PC/Mac) x 1 (USB Type-C), DC Power input x 1 (USB Type-C)
  • GENERAL
    • Sample Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
    • Power Requirements: 5V, 1.5A
    • Power Consumption: 7.5W
  • DIMENSIONS
    • 180mm (W) x 121mm (D) x 42mm (H) (without rubber feet)
  • INCLUDED ACCESSORIES
    • USB 2.0 Cable (Type-A to Type-C, 1.5 m)
    • USB 2.0 Cable (Type-C to Type-C, 1.5 m)
    • Cable hook
    • Rubber feet
    • Owner’s Manual
    • VST Rack Pro Download Information
