The fluid, hands-on workflow simplifies music making with modern vocal recording, pattern generators, thousands of ZEN-Core sounds, mastering effects, and more. Plug-and-play integration with Roland’s Zenbeats app expands your production capabilities using your computer or mobile device.*
Features
- Finish complete songs with inspiring hands-on workflow
- Record vocals with modern effects like Auto-Pitch, Harmonizer, and Doubler
- Curated collection of over 3000 sounds for modern styles from the makers of the TR-808
- 4x4 pads and TR-REC step sequencer for drums, basslines, and melodic parts
- Songwriting tools and generators get you started and keep you flowing
- Interface with your smartphone, tablet, or computer for easy file transfer
- Plug-and-play integration with Roland Zenbeats app expands your production capabilities*
- High-quality mixing and mastering effects for pro results
- Make music on the move with power via a mobile battery or USB
- Built-in mic and XLR mic input with phantom power
- Stereo ¼-inch I/O, dual headphones jacks, and MIDI I/O
Specifications
- Sound Generator: ZEN-Core (Tone, Drum Kit)
- Track Type: Tone, Drum Kit, Looper (Audio Loop)
- Maximum Polyphony:
- ZEN-Core: 128 voices (varies according to the sound generator load)
- Looper: 8 (varies according to the available number of Looper track)
- Vocal Take: 16 (varies according to the vocal take size)
- Tracks: 7 tracks and 1 vocal track
- Sections: 16 sections
- Vocal Take: 16 takes
- Tones:
- Preset Tone: 3,000 or greater
- Preset Drum Kit: 80 or greater
- User Sample (as a Tone or Drum Kit): available by importing from SD card
- Looper Sample (as a clip of Looper track): available by importing from SD card, recording via EXT IN/Tracks
* Available total time for User Sample and Vocal take: 12 minutes in mono, 6 minutes in stereo (44.1 kHz)
* Available format of User Sample: WAV 32--96 kHz/16-bit, 24-bit (mono, stereo)
* Available total time for Looper Sample: Approx. 60 sec (44.1 kHz)
* Available format of Looper Sample: WAV 44.1 kHz/16-bit, 24-bit, 32-bit, 32-bit float (mono, stereo)
- Effects:
- Track Multi-Effects: 90 types
- Track EQ
- Chorus/Delay: 9 types
- Reverb: 7 types
- Master Effects: 90 types
- Master Compressor
- Master EQ
- Step Sequencer: Maximum Step: 128 steps *Available on a Tone or Drum Kit Track
- Looper: Time Stretch, Pitch Shift *Available on a Looper Track
- Display: 16 characters, 2 lines LCD (with backlit)
- External Storage: SD card (SDHC supported) for saving Project Data and Audio Data
- Connectors:
- PHONES jacks: Stereo 1/4-inch phone type, Stereo miniature phone type
- MIX OUT (L/MONO, R) jacks: 1/4-inch phone type
- EXT IN (L/MONO/MIC, R) jacks: 1/4-inch phone type
- MIC IN: XLR type (phantom power: +48 V, 10 mA Max.)
- MIDI (IN, OUT1) connectors
- USB port: USB B type (Audio, MIDI)
- DC IN jack
- Power Supply: AC adaptor; Obtained via USB port (USB bus power)
- Current Draw: 2,000 mA (AC adaptor); 500 mA (USB bus power)
- Accessories:
- Leaflet "Read Me First"
- AC adaptor
- SD card (installed in the product when shipped from the factory)
- SD card protector
- SIZE AND WEIGHT:
- Width: 354 mm; 13-15/16 inches
- Depth: 208 mm; 8-3/16 inches
- Height: 60 mm; 2-3/8 inches
- Weight: 1.165 kg; 2 lbs 10 oz
