Radial HotShot ABi Balanced Input Footswitch Selector

Easily select between two balanced inputs on stage using the HotShot ABi's single latching footswitch to select between sources, allowing you to switch between two dynamic microphones during a performance, alleviating the need for using additional unnecessary channels on the mixer. The latching footswitch can also be used for a myriad of other useful applications, such as using the HotShot ABi as a switch to mute a microphone, alternate between wireless receivers, or switch between two mono playback devices.

• Using ABi to Select Between Two Microphones - In some scenarios, the performer may wish to switch between two microphones that are located in different places on stage - the ABi makes it simple to switch between them with a single foot stomp.
• Using the ABi to Select Between Two Sources - The ABi is perfect for quickly selecting between two mono audio sources - simply connect the first device to input-A, and the second to input-B. Just stomp the switch to select!
• Using the ABi to Mute a Signal - By connecting a source to input A, and nothing to input B, you can use the HotShot ABi as a mute switch. By switching inputs, the non-connected input acts as the mute circuit.

• Circuitry: Passive, True Bypass
• Frequency Response: 20Hz - 20kHz
• Dynamic Range: Unlimited
• Features
  • Input Pad
  • Ground Lift
• Connectors
  • Input: 2x XLR
  • Output: 1x XLR
• Construction: 14-Guage Steel
• Dimensions
  • 99mm (L) x 92mm (W) x 51mm (D)
  • 0.56kg
