MOOG LABYRINTH PARALLEL GENERATIVE ANALOG SYNTH

The Make Noise Labyrinth is a deeply expressive semi-modular instrument designed for evolving, unpredictable sound exploration. Built for producers and experimental musicians, it transforms simple ideas into shifting, atmospheric sonic landscapes with a distinctly organic character. Equally suited for standalone creation or integration into larger setups, it delivers a rich, immersive workflow that encourages discovery, spontaneity, and endlessly evolving musical direction.

Features

• Dual generative sequencers create evolving, chance-driven eight-step patterns that form interweaving rhythmic and melodic motion

• Comprehensive patch bay enables deep integration with analog clock, MIDI, and external modular systems for flexible routing and control

• Designed for interactive performance, allowing real-time improvisation alongside instruments like Matriarch and other modular setups

• Pairs seamlessly with companion instruments such as Spectravox and Mavis for expanded sonic and modular interaction

• Produces rich analog character through sine oscillators, ring modulation, through-zero FM, and saturating mixer stages

• Wavefolding circuit delivers smooth yet harmonically complex tone shaping for dynamic sound design

• State-variable filter morphs continuously between lowpass and bandpass responses for evolving tonal movement

• Supports intricate sound layering and modulation for percussive textures and slowly unfolding melodic sequences

• Encourages experimental patching workflows that generate continuously shifting sonic patterns and textures

Specifications

General
Sound Source: VCO, MOD VCO, RING MOD, Noise Generator

Signal Processors
Voltage-Controlled Wavefolder: 1x
Voltage-Controlled State-Variable Filter: 1x
Voltage-Controlled Amplifiers: 2x

Sequencer
Dual Generative Sequencer: 2x 8-step Generative Digital Sequencers

Patch Bay
Patch Bay Jacks: 32 x 3.5mm
Inputs: 20 Input Jacks
Outputs: 12 Output Jacks

Audio Output
Audio Out: 1⁄4” TRS Headphone or 1⁄4” TS Instrument

Security
Security: Kensington Lock Slot

Power
Power Supply: Wall Adapter; Barrel Connection; Center-Pin Positive
Input: 100 – 240VAC; 50 Hz – 60 Hz
Output: +12VDC; 1200mA
Power Consumption: 4.0 Watts
Eurorack Current Draw: 290 mA (maximum) from +12VDC (10-pin header)

Physical
Mounting Dims: 60HP (18mm Module Depth)
